Understanding Memcached

Understanding Memcached

What is Memcached?

From memcached.org:

Memcached is Free & open source, high-performance, distributed memory object caching system, generic in nature, but intended for use in speeding up dynamic web applications by alleviating database load. Memcached is an in-memory key-value store for small chunks of arbitrary data (strings, objects) from results of database calls, API calls, or page rendering.

How Memcached Works

  • Memcached assign memory that can be used to store data item via (-m) option. In ElastiCache this was configured using max_cache_memory parameter in parameter group. Value of max_cache_memory parameter cannot be changed. This is not directly requested to operating systems when
  • Memcached split the memory into small part called page. A page in Memcached have fixed size of 1 MB. (source code reference)
  • Memcached is having a concepts of slabs to manage memory. On start, memcached will define slab classes.
  • Each slab class will have its own chunk size. Chunk size for each slab class is defined by the following elasticache parameters.
    • chunk_size (default : 48 (bytes))
    • chunk_size_growth_factor (default : 1.25)
    • slab_chunk_max (default : 524288 (bytes))
  • When we store item in Memcached, it will find slab class with chunk size that fit with key-value data size and additional metadata. If the total data is not fit to a slab class, it will use the next slab class
  • If no chunk left on a page for a slab class Memcached will allocate another page and put them on the same slab class.

Memory Waste in Memcached

  • There are two potential memory waste from
  • Once a chunk is used to store an item, the remaining free space cannot be used to store another item or part of another items.
  • Since Memcached is requesting memory per page (1MB), the memory is already allocated for specific slab class even if only 1 chunk is being used on the slab class.

Clustering in memcached

  • Clustering in Memcached is just a bunch of nodes
  • No communication / replication between nodes
  • There is no master node, slave / replica nodes
  • Server rely on client (application that use Memcached) hashing mechanism to know which node in cluster have the key value it needs.

Limits

  • Max key size is 250 bytes (source code reference)
  • Max Item Size is 1 MB by default
    • 1M (from start)
    • 128 M (since version ?)
    • 1G (since version ?)

Memcached Slab Classes

Below table is reference of Memcached slab classes with its chunk size using default settings (default parameter group)

Slab Class Chunk Size (bytes) Chunks Per Page Usable space per chunk (Chunk Size – 48 bytes metadata)
1 96 10922 48
2 120 8738 72
3 152 6898 104
4 192 5461 144
5 240 4369 192
6 304 3449 256
7 384 2730 336
8 480 2184 432
9 600 1747 552
10 752 1394 704
11 944 1110 896
12 1184 885 1136
13 1480 708 1432
14 1856 564 1808
15 2320 451 2272
16 2904 361 2856
17 3632 288 3584
18 4544 230 4496
19 5680 184 5632
20 7104 147 7056
21 8880 118 8832
22 11104 94 11056
23 13880 75 13832
24 17352 60 17304
25 21696 48 21648
26 27120 38 27072
27 33904 30 33856
28 42384 24 42336
29 52984 19 52936
30 66232 15 66184
31 82792 12 82744
32 103496 10 103448
33 129376 8 129328
34 161720 6 161672
35 202152 5 202104
36 252696 4 252648
37 315872 3 315824
38 394840 2 394792
39 524288 2 524240

Large Item Size in Memcached

  • Before version 1.4.29 max-item-size parameter is tied largest chunk size.

Benefit Upgrading to Memcached 1.5.10

  • Cumulative fixes, such as ASCII multigets, (CVE-2017-9951) Fixed in [Memcached 1.4.39](https://github.com/memcached/memcached/wiki/ReleaseNotes1439) and (limit crawls for metadumper).
  • Better connection management by closing connections at the connection limit.
  • Improved item-size management for item size above 1MB.
    • Before version 1.5.0 Item larger than 1 MB is always using largest slab size (around 512k). For example if we store 700 k item it will use two chunks in slab 39 (chunk size 524288). Since we only use 700k on two chunk of slab class 39 we will waste around 300k of memory
    • Starting on version 1.5.0, Memcached will use multiple slab class that minimize memory waste.
  • Better performance and memory-overhead improvements by reducing memory requirements per-item by a few bytes.
    • On Version 1.4.39 (Release Notes) : save four bytes per item if client flags is set to 0.
